Parameter:
|
Product Model Product Item |
BY-GKC1-100W |
|
LED chip |
PHILIPS |
|
LED Model |
SMD2835 -1W |
|
LED QTY |
212PCS |
|
Power |
100W |
|
Power Efficiency |
> 92% |
|
Lumen |
15500-16200lm Cool white 15000-15500lm Pure White 14500-15000lm Warm White |
|
Color temperature(C.C.T/K) |
3000-3500K Warm White 4000-5500K Pure White 5500-6500K Cool White |
|
Lamp Luminous Efficiency |
150LM/W |
|
Color Rendering Index (CRI) |
>80Ra |
|
Beam Angle(degree） |
60°/90°/120° |
|
Light Distribution Curve (Beam Pattern) |
Symmetric / Cone Beam |
|
Driver(Power supply) |
MeanWell,/ SOSEN (Options) |
|
Input Voltages |
AC 90-305V,( supply 347V/480V) |
|
Frequency Range |
47-63 Hz |
|
Power factor (P.F.) |
>0.98 |
|
Total Harmonic Distortion |
<10% |
|
Junction Temperature |
50℃ ± 10%(ta=25℃) |
|
Surge |
4/6KV, (10KV with SPD) |
|
Storage Temperature |
－40℃--+80℃ |
|
Working temperature |
-45º~55℃ |
|
IP Rating |
IP65/IP66 |
|
Mechanical Impact |
IK10 |
|
Insulation CLASS |
Class II |
|
Lamp base |
Hook / U Shape Bracket (options) |
|
Dimension |
φ183*202mm |
|
Working life-span |
>50000 Hrs |
|
Net weight(g) |
2.1kgs |
|
Warranty time |
5 years |
