Product Items |
BY-TP-60L15 |
|
LEDs |
Samsung SMD2835 |
|
Power |
60W |
|
Lamp Luminous Flux |
7000-7500lm |
|
Color Temperature |
2700-6500K |
|
Power Efficiency |
> 92% |
|
Color temperature(C.C.T/K) |
2700-6500K |
|
Lamp Luminous Efficiency |
>130lm/w |
|
Color Rendering Index (CRI) |
>80 |
|
Beam Angle(degree） |
120 |
|
Light Distribution Curve (Beam Pattern) |
Asymmetric |
|
Driver(Power supply) |
OSRAM |
|
Input Voltages |
AC200-240V/100-277V |
|
Frequency Range |
47-63 Hz |
|
Power factor (P.F.) |
>0.98 |
|
Surge |
4/6KV |
|
Total Harmonic Distortion(THD) |
<10% |
|
Junction Temperature |
50℃ ± 10%(ta=25℃) |
|
Storage Temperature |
－40℃--+80℃ |
|
Working temperature |
-45º~65℃ |
|
IP Rating |
IP66 |
|
Mechanical Impact |
IK10 |
|
Insulation CLASS |
Class II |
|
Materials |
Aluminum+PC plastic |
|
Dimension |
1500*65*75mm |
|
Working life-span |
>50000 Hrs |
|
Warranty time |
5 years |
