Product Item |
BY-KLD-120W |
|
LED chip |
CREE |
|
LED Model |
CREE 3030 |
|
LED QTY |
196PCS |
|
Power |
120W |
|
Lamp Luminous Efficiency |
150LM/W |
|
Beam Angle(degree） |
30°/60°/90°/ 120°/ 70°X155°/80°X155 |
|
Lumen |
18000-19000lm |
|
Color temperature(C.C.T/K) |
2700-6500K |
|
Power Efficiency |
> 92% |
|
Color Rendering Index (CRI) |
>80Ra |
|
Driver(Power supply) |
Taiwan MeanWell |
|
Input Voltages |
AC90-305V |
|
Frequency Range |
47-63 Hz |
|
Power factor (P.F.) |
>0.98 |
|
Total Harmonic Distortion(THD) |
<10% |
|
Junction Temperature |
50℃ ± 10%(ta=25℃) |
|
Storage Temperature |
－40℃--+80℃ |
|
Working temperature |
-45º~65℃ |
|
IP Rating |
IP66/IP65 Waterproof |
|
Mechanical Impact |
IK08 |
|
Insulation CLASS |
Class II |
|
Dimension |
710*290*125MM |
|
Lamp base |
Adjustable Adapter |
|
Lamp base hole size |
62/52/48MM |
|
Working life-span |
>50000Hrs |
|
Warranty time |
5years |
