Round/Square led panel light 25W

Your location：Home >> Round/Square led panel light 25W

Product Name：Round/Square led panel light 25W

Product Model：

Description

Parameter:

Product Item	BY-RDL280-25W	BY-FXP-25W
LED Qty	125pcs	125pcs
Dimension	ø300×20mm	300X300x20mm
Cut out size	ø280mm	280X280mm
Power	25W
Lumen	2500-2800lm
LED chip	High Bright SMD2835
luminous efficacy	100-120lm/w
CRI	>80Ra
CCT	2700-9000K
Bean angle	120 °
Driver	External
Input voltage	AC85-265V,50/60Hz
PF	>0.96
Material	Aluminum + LGP + Lighting diffuser plate+ reflective sheeting
Instaltion	Recessed/Mounted
Work Temperature	-45-55℃
Storage Temperature	-45-65℃
Life	>40000Hrs
Warranty time	3 years, 5 Years for option

Feature：
1.Using Hi-quality, Hi-brightness LED SMD2835 as lighting source,
2.high efficiency and energy-saving, free from glare and flicker, and has average luminous surface.
3.Adopting lampshade materials with more than 90% light transmittance, and aluminum alloy of high thermal conduction as lamp shell.
4.Long-lifespan on average over 50 thousand hours is more than 10 times of traditional lamps
5.Decrease the maintenance fee, can be used for a long time without changing for new one.
6.Directly replace the traditional lamp, No additional construction.
7.anti-shock, and easy installation.
8.Energy saving than traditional fixture about 70%～80%
9.ECO-Friendly, CO2 reduction, Mercury-free, No UV light
10.No glaring、The light is soft and bright., Meet the standards for lighting
11.No noise and flicker during working time, witching frequency, affect the light source life
12.Lamp passed CE&ROHS&FCC UL……standards regulations
