Parameter:
|
Product Item |
BY-SPB-P1000P/WWA |
BY-SPB-P1200P/WW |
|
Power |
1000W |
1200W |
|
Lumen |
145000-146000lm |
162000-163000lm |
|
Lamp Luminous Efficiency |
150LM/W |
140-150LM/W |
|
Beam Angle(degree） |
10°/25°/60° | |
|
LED chip |
Philips | |
|
LED Model |
Philips5050 | |
|
LED QTY |
392pcs | |
|
Power Efficiency |
> 92% | |
|
Color temperature(C.C.T/K) |
2700-4000K Warm White 4000-5500K Pure White 5500-7000K Cool White | |
|
Color Rendering Index (CRI) |
>80Ra | |
|
Light Distribution Curve (Beam Pattern) |
Symmetric /Rectangle Beam | |
|
Driver(Power supply) |
MeanWell(Made in Taiwan) | |
|
Input Voltages |
AC 90-305V/347V/480V | |
|
Frequency Range |
47-63 Hz | |
|
Power factor (P.F.) |
>0.98 | |
|
Total Harmonic Distortion(THD) |
<10% | |
|
Storage Temperature |
－40℃--+80℃ | |
|
Working temperature |
-45º~65℃ | |
|
IP Rating |
IP65/IP66 | |
|
Mechanical Impact |
IK10 | |
|
Surge |
4/6KV, if 10KV, it need to add the SPD | |
|
Insulation CLASS |
Class II | |
|
Corrosion prevention |
yes | |
|
Withstand wind |
17 levels | |
|
Materials |
Aluminum +Lens | |
|
Dimension |
420X900X270mm | |
|
Lamp base |
Hook/Mounted installation | |
|
Working life-span |
>50000 Hrs | |
|
Net weight(g) |
23kgs | |
|
Warranty time |
5 years | |
Feature
1.Use advanced aluminum as heat dissipation body
2.High power CREE-XTE or Philips5050 chip LEDs.
3.Waterproof of level is IP65/IP66. Can used in outdoor.
4.Adopt Meanwell Model driver (AC90-305V). Also supply AC347/480V
5.Use the aluminum reflector to control bean angle, 10°/25°/60°
6.Meet the specifications of the traditional lamp, can replace the traditional mercury lamp without additional construction.
7.Energy saving than traditional fixture about 70%～80%.
8.Main part of heat dissipation is under the protection of several patents
9.Adapter is compliance with CE&ROHS&PSE&FCC &ETL&ETL, TUV SAA……standard regulations.
