Parameter:
Product Item BY-HBUFO-200W LED chip CREE LED Model CREE 3030 LED QTY 272PCS Lamp Luminous Efficiency 140-150LM/W Lumens 28000-30000lm Power 200W Power Efficiency > 92% Color temperature(C.C.T/K) 2700-4000K Warm White 4000-5500K Pure White 5500-6500K Cool White Color Rendering Index (CRI) >80Ra Beam Angle(degree） 60°/90°/120° Light Distribution Curve (Beam Pattern) Symmetric / Cone Beam Driver(Power supply) Meanwell(Made in Taiwan) Input Voltages AC 85-265V/277V/305V/347V/480V Frequency Range 47-63 Hz Power factor (P.F.) >0.96 Total Harmonic Distortion(THD) <15% Junction Temperature 50℃ ± 10%(ta=25℃) Storage Temperature －40℃--+80℃ Working temperature -45º~65℃ IP Rating IP65/IP66 Mechanical Impact IK10 Insulation CLASS Class II Dimension φ380*59mm Lamp base Hook Working life-span >50000 Hrs Net weight(g) 5.9kgs Warranty time 5 years Feature 1.Use high pure aluminum as heat dissipation body
2. Use USA CREE LEDs.
3.Waterproof of level is IP65/66. Can used in outdoor.
4.Adopt Meanwell driver (AC90-305V). Also supply AC347/480V
5.Use the aluminum reflector to control bean angle, 60°/90°120°
6.Meet the specifications of the traditional lamp, can replace the traditional mercury lamp without additional construction.
7.Energy saving than traditional fixture about 70%～80%.
8.Main part of heat dissipation is under the protection of several patents
9.Adapter is compliance with CE&ROHS&FCC UL……standard regulations.
