Parameter: Product Items BY-CNL-100W-P/WW LEDs CREE3030 Power 100W LED Qty 112pcs Lamp Luminous Flux 12000-13000lm Beam Angle(degree） 60°/90 LED Luminous Efficiency 160-170lm/w Power Efficiency > 93% Color temperature(C.C.T/K) 2700-6500K Lamp Luminous Efficiency >120lm/w Color Rendering Index (CRI) >80 Light Distribution Curve (Beam Pattern) Asymmetric (Bat Wing) / Rectangular Beam Driver(Power supply) Meanwell(Made in Taiwan) Input Voltages AC 90-305V/347/480V Frequency Range 47-63 Hz Power factor (P.F.) >0.96 Total Harmonic Distortion(THD) <15% Junction Temperature 50℃ ± 10%(ta=25℃) Storage Temperature －40℃--+80℃ Working temperature -45º~65℃ IP Rating IP65/IP66 Mechanical Impact IK10 Insulation CLASS Class II Dimension 365*270*125 Cutout size 364x364mm Installation Mounted and Suspended/Recessed Working life-span >50000 Hrs Warranty time 5 years Features
1.The advanced aluminum as heat sink body
2.Use Philips3030/ Bridgelux45mil/CREE-XTE LEDs
3.Adopt the Meanwell driver
4.Installation has Mounted and Suspended/Recessed
5.Dimmable(RCL) or no dimmable option for your option
6.Independent power supply design, Corrosion resistance is strong
7.Low heat, no hot-radioactive, non-mercury, sodium and other elements harmful to human health
8.LED light is all-solid-body, resist impact, not easy broken, waste recycling pollution-free
9.Energy saving than traditional fixture about 70%～80%.
10.Meet the specifications of the traditional lamp can directly replace the traditional lamp, No additional construction
11.Adapter is compliance with CE&RoHS&FCC&PSE UL……standard regulations
